Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction machines. Machines like aerial lifts, manlifts and boom lifts. These types of machines are designed to facilitate access to difficult to reach areas, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains steps or handholds or paltforms which are connected to the unit in order to move personnel from each floor.
TB85
Terex's TB85 man lift offers a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is about 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
